The UMCAN1044N is a high-speed CAN transceiver that provides an interface between a Controller Area Network (CAN) protocol controller and the physical two-wire CAN bus. The transceiver is designed for high-speed CAN applications in the automotive industry, providing the differential transmit and receive capability to (a microcontroller with) a CAN protocol controller.

The UMCAN1044N offers a feature set optimized for 12 V automotive applications and excellent ElectroMagnetic Compatibility (EMC) performance. Additionally, the UMCAN1044N features:

• Ideal passive behavior to the CAN bus when the supply voltage is off

• A very low–current Standby mode with bus wake–up capability

• Excellent EMC performance, even without a common mode choke

The UMCAN1044N implements the CAN physical layer as defined in ISO 11898-2:2024 and SAE J2284-1 to SAE J2284-5. This implementation enables reliable communication in the CAN FD fast phase at data rates up to 5 Mbit/s. Up to 8Mbit/s operation in simpler networks is possible with these devices. These features make the UMCAN1044N an excellent choice for all types of HS-CAN networks, in nodes that require a standby mode with wake-up capability via the bus.

- Fully ISO 11898-2:2024, SAE J2284-1 to SAE J2284-5 and SAE J1939-14 compliant

- Supply Voltage: 4.5V to 5.5V

- Very low-current Standby mode with local and bus wake-up capability

- Optimized for use in 12 V automotive systems

- Low Electromagnetic Emission (EME) and high Electromagnetic Immunity (EMI), according to proposed EMC Standards IEC 62228-3 and SAE J2962-2

- Up to 8 Mbps operation in simpler networks

- High–speed CAN applications in the automotive industry

- Infrastructure and farm equipment/p>

- Elevator

- Networked sensors/actuators
